XRC635 Series Adhesive-lined Leaded Vinyl

Leaded x-ray protective material with Pressure Sensitive Adhesive backing. General purpose use for x-ray cabinets, medical and general NDT radiation shielding. Lead-free vinyl skin for safer handling and improved strength.

Use for protection from gamma radiation or x-ray tubes.
- Lead equivalent thicknesses from 0.25mm Pb to 1.0mm Pb.
- Sheets and roll sizes up to 4 ft or 1200mm width.

Adhesive Properties

- Special acrylic adhesive with excellent chemical resistance and bond strength even at elevated temperatures.
- Long Term Temperature Resistance -40 °C to 120 °C
- Bonds well to a wide variety of plastics, powder coatings and metals.

Peel Adhesion by ASTM D3330:
- 16.4 N/cm Stainless Steel
- 15.8 N/cm Painted Metal
- 9.3 N/cm ABS
- 9.8 N/cm Polyvinyl chloride (PVC)
- 10.0 N/cm Aluminum

Download Technical Data Sheet for

Product Options and Formats

All product is made to order to ensure quality of the adhesive material.  Standard roll size is 600mm by 1200mm (2 ft x 4 ft).  Product is available with larger roll sizes, precut panels, and custom cut shapes.
